Description

ENGINE

  • Type: 3-cylinder, CRDI, liquid-cooled, Diesel, NA
  • Model (Tier 4): L3C19-D2
  • Engine HP (Gross): 35
  • PTO HP: 29.7
  • Rated Speed (RPM): 2,600
  • Displacement (cu. in.): 114.7
  • Fuel Tank Capacity (gal): 7.4
  • Alternator (A-V): 12V – 70

DRIVE TRAIN

  • Transmission: Syncro Shuttle
  • No. of Speeds: F12 x R12
  • Brakes: Wet, Multi-Disc
  • Steering: Hydrostatic Power Steering

PTO

  • Type: Independent
  • Rear, rpm: 540 (Standard)
  • Mild, rpm: 2,000 (Option)

HYDRAULIC SYSTEM

  • Control System: Position
  • Implement pump (gpm): 8.2
  • Steering pump, gpm: 4.1
  • Total flow (gpm): 12.3
  • Category, 3 pt hitch: CAT 1
  • Hitch Lift capacity (lb): 1,808
  • Remote Valves: Option

DIMENSIONS

  • Overall length, Frame to link (in.): 121
  • Wheelbase (in.): 69
  • Overall width tires (in.): 54
  • Height to top of ROPS (in.): 88

TIRE SIZE

  • Ag Front/Rear: 7 – 14 / 11.2 – 24
  • IND Front / Rear 25 x 8.5 – 14 / 43 x 16 – 20
  • Turf Front / Rear 25 x 8.5 – 14 / 41 x 14 – 20

WEIGHT

  • Total weight without ballast (lbs.): 2,866
