Description

ENGINE

  • Type: 3 Cylinder, liquid-cooled, Diesel, NA, IDI
  • Model (Tier 4): S3L2
  • Engine HP (Gross): 24.6
  • PTO HP: 19.2
  • Rated Speed (RPM): 2,500
  • Displacement (cu. in.): 80.4
  • Fuel Tank Capacity (gal): 7.4
  • Alternator (V-A): 12 – 50

DRIVE TRAIN

  • Transmission: Synchro shuttle
  • No. of Speeds: F12 x R12
  • Brakes: Wet, Multi Disc
  • Steering: Hydrostatic Power Steering

PTO

  • Type: Independent
  • Rear (rpm): Standard (540)

HYDRAULIC SYSTEM

  • Control System: Position
  • Implement pump (gpm): 7.9
  • Steering pump (gpm): 4.6
  • Total flow (gpm): 12.5
  • Category, 3 pt hitch: CAT 1
  • Hitch Lift capacity (lb): 1,808
  • Remote Valves: Option

DIMENSIONS

  • Overall length, Frame to link, (in.): 118
  • Wheelbase (in.): 66
  • Overall width with tires, in. (in.): 54
  • Height to top of ROPS (in.): 88

TIRE SIZE

  • Ag Front/Rear: 7 – 14 / 11.2 – 24
  • IND Front / Rear 25 x 8.5 – 14 / 43 x 16 – 20
  • Turf Front / Rear 25 x 8.5 – 14 / 41 x 14 – 20

WEIGHT

  • Total weight without ballast (lbs.): 2,434
