Description

ENGINE

  • Type: Vertical Water-Cooled 4Cycle Diesel Engine
  • Model:L3C19-T
  • Engine HP (KW): 50 (37.3)
  • PTO HP: 42.5
  • Rated Speed (RPM): 2,600
  • Displacement (cu. in.): 114.7
  • Fuel Tank Capacity (gal): 13.7

DRIVE TRAIN

  • Transmission: Synchro Shuttle / Constant mesh
  • No. of Speeds: F8 × R8
  • Brakes: Wet, Multi Disc

PTO

  • Type: Independent
  • Rear, rpm: 540

HYDRAULIC SYSTEM

  • Implement pump (gpm): 8.2
  • Steering pump (gpm): 4.8
  • Total flow (gpm): 13.0
  • Category, 3 pt hitch: CAT 1
  • Hitch Lift capacity (lb): 2,910
  • Remote valves: 2 pairs (Front), 1/2 pairs (Rear, Option)
  • Steering: Hydrostatic Power Steering

DIMENSIONS

  • Overall length, Bumper to link (in.): 125
  • Wheelbase (in.): 74.8
  • Overall width with tires, in.: 68
  • Height to top of rops, in. (in.): 100

TIRE SIZE

  • Ag (Front/Rear): 9.5-16 / 14.9-24
  • IND (Front / Rear) 10.0-16.5 / 17.5L-24
  • Narrow Ag (Front / Rear): 7.0 – 14 / 9.5 – 24
  • Turf tire (Front / Rear): 29 x 12.50-15 / 44 x 18.00-20

WEIGHT

  • Total weight without ballast (lbs.): 3,724
