Description

ENGINE

  • Type: 3-cylinder, Indirect-injection, Water-cooled
  • Model (Tier 4 ): Mitsubishi S3L2
  • Engine HP (Gross): 24.4
  • PTO HP: 19.5
  • Rated Speed (RPM): 2,500
  • Displacement (cu in): 80.4
  • Fuel Tank Capacity (gal): 6.6
  • Alternator: 12V – 50 Amps

DRIVE TRAIN

  • Transmission: Sliding Shift
  • No. of Speeds: 6F X 2R
  • Brakes: Wet, Multi Disc
  • Steering: Hydrostatic Power Steering

PTO

  • Type: Independent
  • Mid PTO: Standard (2000 rpm)
  • Rear PTO: Standard (540 rpm)

HYDRAULIC SYSTEM

  • Implement pump (gpm): 6.9
  • Steering pump (gpm): 1.1
  • Total flow (gpm): 8.0
  • Category, 3 pt hitch: CAT 1
  • Hitch Lift capacity (lb.): 1,433
  • Lift control type: Manual Position

DIMENSIONS

  • Overall length with 3pt (in.): 103
  • Wheelbase (in.): 59
  • Min. overall width with IND tires (in.): 44.9
  • Height to top of ROPS (in.): 92.3

TIRE SIZE

  • Industrial Front/Rear: 23 x 8.5 – 12 / 33 x 12 -16.5
  • Turf Front/Rear: 23x 8.5 – 12 / 33 x 12.5 – 16.5

WEIGHT

  • Total weight without ballast (lbs): 1,785
